Blossom Steel & Engineering Co is a dynamic gathering, which was set up completed 10 years back to consider making asking for of ASME B16.47 Ser. A Class 600 Weld Neck Flanges benchmarks in Weld Neck Flanges, Blind Flanges in all materials like Stainless Steel, Carbon Steel and High Nickel Alloys. We Manufacture, Export and Supply Flanges which meets with national and general quality models and passing on base which claims sorts of apparatus changing according to general particular level and is all around equipped with a whole system of front line plasma refining supplies.


SPECIFICATIONS OF ASME B16.47 SER. A CLASS 600 WELD NECK FLANGES

Stainless Steel ANSI B16.47 Ser. A Class 600 Weld Neck Flanges| Carbon Steel ANSI B16.47 Ser. A Class 600 Weld Neck Flanges| Nickel Alloys ANSI B16.47 Ser. A Class 600 Weld Neck Flanges

Size : 1/2"NB TO 60"NB IN
Pressure: Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500
Standard: ANSI B16.47, ASME B16.47
Type: Blind Flange, Blank Flange (Raised Face)
Process: Forged and Stamped

Face Type:Raise Face (RF)

Coating: Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized

Dimension:
ANSI/ASME B16.5, ANSI/ASME B16.47 Series A (MSS SP-44), ANSI/ASME B16.47 Series B (API 605),ANSI/ASME B16.36, ANSI/ASME B16.48 (API 590)


Execution

ASME

Welding Neck Flanges

B 16.5 / 16:47

Blind Flanges

B 16.5 / 16:47

Slip On Flanges

B 16.5

Lap Joint Flanges

B 16.5

Threaded Flanges

B 16.5

Socket Welding Flanges

B 16.5

Long Welding Neck Flanges

B 16.5

Orifice Flanges

B 16:36

Spectacle Blind

B 16:38

Flanges to BS 3293 / API 6A, as well as drawing


DIMENSIONS OF ASME B16.47 SER. A CLASS 600 WELD NECK FLANGES

Pipe Normal Diam.

O.D.
OF
Flange

Thick
ness

Length
Through
Hub

Diam. of
Hub
at Base

Hub
Diam.
Top

Raised
Face
Diam.

Diam. of
Bolt
Circle

No. of
Bolt
Holes

Diam. of
Bolt
Holes

Diam. of
Bolt

Fillet
Radius
Min.

inch

O

C

Y

X

A

R

BD

BN

BH

DB

r1

26"

971.6

79.2

184.2

720.9

660.4

749.3

876.3

28

44.5

1 5/8

9.7

28"

1035.1

85.9

196.9

774.7

711.2

800.1

939.8

28

44.5

1 5/8

11.2

30"

1092.2

91.9

209.6

827

762

857.3

997

28

47.8

1 3/4

11.2

32"

1149.4

98.6

222.3

881.1

812.8

914.4

1054.1

28

50.8

1 7/8

11.2

34"

1206.5

101.6

231.6

936.8

863.6

965.2

1104.9

28

50.8

1 7/8

12.7

36"

1270

104.6

241.3

990.6

914.4

1022.4

1168.4

32

53.8

2

12.7

38"

1168.4

108

180.8

993.6

965.2

1028.7

1092.2

32

41.1

1 1/2

12.7

40"

1238.3

114.3

193.5

1047.8

1016

1085.9

1155.7

32

44.5

1 5/8

12.7

42"

1289.1

119.1

200.2

1098.6

1066.8

1136.7

1206.5

32

44.5

1 5/8

12.7

44"

1352.6

124

206.2

1149.4

1117.6

1193.8

1263.7

32

47.8

1 3/4

12.7

46"

1416.1

128.5

215.9

1203.5

1168.4

1244.6

1320.8

28

50.8

1 7/8

12.7

48"

1466.9

133.4

223.8

1254.3

1219.2

1301.8

1371.6

32

50.8

1 7/8

12.7

50"

1530.4

139.7

231.6

1305.1

1270

1358.9

1428.8

32

53.8

2

12.7

52"

1581.2

144.5

238.3

1355.9

1320.8

1409.7

1479.6

32

53.8

2

12.7

54"

1657.4

152.4

252.5

1409.7

1371.6

1466.9

1549.4

28

60.5

2 1/4

12.7

56"

1708.2

153.9

260.4

1463.5

1422.4

1517.7

1600.2

28

60.5

2 1/4

12.7

58"

1759

158.8

266.7

1514.3

1473.2

1574.8

1651

32

60.5

2 1/4

12.7

60"

1809.8

163.6

273.1

1565.1

1524

1625.6

1701.8

32

60.5

2 1/4

12.7
