Class 300 Ansi Norm Flanges
Class 300 Ansi Norm Flanges
Ansi Norm Class 300 Flanges Manufacturers, Ansi Norm Class 300 Flanges Exporters, Ansi Norm Class 300 Flanges Suppliers, Ansi Norm Class 300 Flanges Importers. Slip On Flanges, SORF, Socket Weld Flange, SWRF, Blind Flange, BLRF, Ansi Norm Flange, WNRF, Threaded, Screwed Flange, Lap Joint Flanges, Long Ansi Norm Flanges, Spectacle Blind Flanges, Spade, Paddle Blanks/Blinds, Ring Spacers Paddle Spacers Flange Manufacturer in India, Flange Suppliers in India. Ansi Norm Flanges 300 Manufacturer & Trader | Carbon Steel and Stainless Steel 300 Ansi Norm Flanges Exporter | Raised Face Ansi Norm Flanges Suppliers.
Ansi Norm Class 300 Flanges Manufacturers in India, Ansi Norm Class 300 Flanges Exporters in India, Ansi Norm Class 300 Flanges Suppliers in India, Ansi Norm Class 300 Flanges Importers in India. ASME ANSI B16.5 Class 300 LBS Flange, Flange Manufacturer in India, Flange Suppliers in India, Flange Exporters, Flange Stockist, Flange Stockholder, Flange Price in India. Stainless Steel 300 Ansi Norm Flanges Supplier in India | ASTM A182 Steel Ansi Norm Flanges 300 Manufacturer | ASME B16.5 Industrial SS 300 Ansi Norm Flanges.
Ansi Norm Class 300 Flanges Manufacturers in Mumbai, Ansi Norm Class 300 Flanges Exporters in Mumbai, Ansi Norm Class 300 Flanges Suppliers in Mumbai, Ansi Norm Class 300 Flanges Importers in Mumbai. ASME ANSI B16.5 Class 300 LBS Flange Dimensions, Flange Price in India, Flange Dealers, Flange Distributors, ASME ANSI B16.5 Class 300 LBS Flange Specifications, Flange Size, ASME ANSI B16.5 Class 300 LBS Flange at best price with high quality.
Blossom Steel & Engineering Co is a dynamic gathering, which was set up finished 10 years back to oblige making sales of ASME B16.5 Class 300 Flanges gages in Slip On Flanges, Ansi Norm Flanges, Blind Flanges in all materials like Stainless Steel, Carbon Steel and High Nickel Alloys. We Manufacture, Export and Supply Flanges which meets with national and general quality gages and passing on base which has sorts of mechanical assembly consenting to general specific level and is all around equipped with an entire course of action of forefront plasma refining supplies.
SPECIFICATIONS OF ASME B16.5 CLASS 300 FLANGES
Stainless Steel ANSI B16.5 Class 300 Flanges| Carbon Steel ANSI B16.5 Class 300 Flanges| Nickel Alloys ANSI B16.5 Class 300 Flanges
Size : 1/2"NB TO 60"NB IN
Class : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.
Face Type: Flat Face (FF), Raise Face (RF), Ring Joint (RJT)
ASME B16.5 Class 300 Flanges Type: Ansi Norm Flanges, Blind Flanges and Slip On Flanges
Coating: Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized
Dimension:
ANSI/ASME B16.5, ANSI/ASME B16.47 Series A (MSS SP-44), ANSI/ASME B16.47 Series B (API 605), ANSI/ASME B16.36, ANSI/ASME B16.48 (API 590)
|
Execution |
ASME |
|
Welding Neck Flanges |
B 16.5 / 16:47 |
|
Blind Flanges |
B 16.5 / 16:47 |
|
Slip On Flanges |
B 16.5 |
|
Lap Joint Flanges |
B 16.5 |
|
Threaded Flanges |
B 16.5 |
|
Socket Welding Flanges |
B 16.5 |
|
Long Welding Neck Flanges |
B 16.5 |
|
Orifice Flanges |
B 16:36 |
|
Spectacle Blind |
B 16:38 |
|
Flanges to BS 3293 / API 6A, as well as drawing |
|
DIMENSIONS OF ASME B16.5 CLASS 300 Ansi Norm FLANGES
ANSI/ASME/ASA B16.5 300lb/sq.in. Flange WN-RF | |||||||||||
ø | D | b | g | m | a | J* | h | k | Holes | l | Kg. |
1/2" | 95,2 | 14,3 | 34,9 | 38,1 | 21,3 | 15,7 | 52,4 | 66,7 | 4 | 15,9 | 0,900 |
3/4" | 117,5 | 15,9 | 42,9 | 47,6 | 26,7 | 20,8 | 57,1 | 82,5 | 4 | 19,0 | 1,500 |
1" | 123,8 | 17,5 | 50,8 | 54,0 | 33,5 | 26,7 | 61,9 | 88,9 | 4 | 19,0 | 1,900 |
1 1/4" | 133,3 | 19,0 | 63,5 | 63,5 | 42,2 | 35,1 | 65,1 | 98,4 | 4 | 19,0 | 2,600 |
1 1/2" | 155,6 | 20,6 | 73,0 | 69,8 | 48,3 | 40,9 | 68,3 | 114,3 | 4 | 22,2 | 3,300 |
2" | 165,1 | 22,2 | 92,1 | 84,1 | 60,3 | 52,6 | 69,8 | 127,0 | 8 | 19,0 | 3,600 |
2 1/2" | 190,5 | 25,4 | 104,8 | 100,0 | 73,1 | 62,7 | 76,2 | 149,2 | 8 | 22,2 | 5,400 |
3" | 209,5 | 28,6 | 127,0 | 117,5 | 88,9 | 78,0 | 79,4 | 168,3 | 8 | 22,2 | 7,400 |
3 1/2" | 228,6 | 30,2 | 139,7 | 133,3 | 101,6 | 90,2 | 81,0 | 184,1 | 8 | 22,2 | 8,900 |
4" | 254,0 | 31,7 | 157,2 | 146,0 | 114,3 | 102,4 | 85,7 | 200,0 | 8 | 22,2 | 11,900 |
5" | 279,4 | 34,9 | 185,7 | 177,8 | 141,2 | 128,3 | 98,4 | 234,9 | 8 | 22,2 | 16,000 |
6" | 317,5 | 36,5 | 215,9 | 206,4 | 168,4 | 154,2 | 98,4 | 269,9 | 12 | 22,2 | 20,200 |
8" | 381,0 | 41,3 | 269,9 | 260,3 | 219,1 | 202,7 | 111,1 | 330,2 | 12 | 25,4 | 31,000 |
10" | 444,5 | 47,6 | 323,4 | 320,7 | 273,0 | 254,5 | 117,5 | 387,3 | 16 | 28,6 | 44,300 |
12" | 520,7 | 50,8 | 381,0 | 374,6 | 323,8 | 304,8 | 130,2 | 450,8 | 16 | 31,7 | 64,000 |
14" | 584,2 | 54,0 | 412,7 | 425,4 | 355,6 | 336,5 | 142,9 | 514,3 | 20 | 31,7 | 88,000 |
16" | 647,7 | 57,1 | 469,9 | 482,6 | 406,4 | 387,3 | 146,0 | 571,5 | 20 | 34,9 | 113,000 |
18" | 711,2 | 60,3 | 533,4 | 533,4 | 457,2 | 438,1 | 158,7 | 628,6 | 24 | 34,9 | 134,000 |
20" | 774,7 | 63,5 | 584,2 | 587,4 | 508,0 | 488,9 | 161,9 | 685,8 | 24 | 34,9 | 171,000 |
22" | 838,2 | 66,7 | 641,2 | 641,2 | 558,8 | 539,7 | 165,1 | 742,9 | 24 | 41,3 | 195,000 |
24" | 914,4 | 69,8 | 692,1 | 701,7 | 609,6 | 590,5 | 168,3 | 812,8 | 24 | 41,3 | 238,000 |
* | The data "J" corresponds to the STD schedule | ||||||||||
